3 Tuj Gasoline Forklift High Quality Diesel Forklift Truck yog lub siab -kev ua haujlwm forklift tsim los rau cov khoom hnyav thiab ua haujlwm ntev ntev. Lub forklift siv lub siab zoo - diesel cav uas muab lub zog muaj zog, nrog rau kev siv roj zoo thiab kav ntev. Nws cov peev txheej ntsuas yog 3 tons, thiab nws tuaj yeem muaj kev nyab xeeb thiab ruaj khov nqa cov khoom hauv qhov hnyav no.
Cov qauv tsim ntawm lub forklift no tau ua tib zoo ua kom zoo dua qub, suav nrog cov thav duab khov kho, cov diav rawg ruaj khov thiab lwm yam khoom siv kom ruaj ntseg thiab kev ntseeg tau nyob rau hauv ntau yam kev ua haujlwm nyuaj. Nruab nrog kev tswj hwm hluav taws xob siab tshaj plaws thiab cov tshuab tsis siv neeg navigation, nws yooj yim rau kev khiav lag luam thiab tuaj yeem tswj tau qhov txav ntawm lub forklift thiab nqa cov khoom. Tsis tas li ntawd, nws tau nruab nrog cov cuab yeej siv kev nyab xeeb, xws li lub tshuab nres tsheb, lub rooj zaum siv, guardrails thiab lwm yam khoom siv los tiv thaiv kev nyab xeeb ntawm cov neeg ua haujlwm.
Parameter Table
|
Qauv |
LPG/DIESLE/GASOLINE |
FG 30 |
|
Load peev |
kg |
3000 |
|
Kev ua haujlwm |
|
SEAT |
|
Chaw thau khoom |
mm |
500 |
|
Tag nrho qhov hnyav |
kg |
4300 |
|
Log tsheb |
|
Pneumatic / Khoom log |
|
Pem hauv ntej log tsheb loj |
|
28X9-15-12 XAB |
|
Tsheb log tsheb sieze |
|
6.50-10-10 dr hab |
|
Log Number (pem hauv ntej / nram qab) |
|
2/2 |
|
Mast qaij (pem hauv ntej / nram qab) |
deg |
6/12 |
|
Length rau fork ntsej muag |
mm |
2780 |
|
Zuag qhia tag nrho dav (ib lub log) |
mm |
1225 |
|
Qhov siab ntawm backrest |
mm |
1220 |
|
Nqa qhov siab |
mm |
3000-6000 |
|
Height of overhead guard (cabin) |
mm |
2150 |
|
Av clearance nrog load mast |
mm |
135 |
|
Min Right Angle Steering Asile Dav nrog palet 1000 * 1200 hla rab rawg |
mm |
2200 |
|
Min.Right Angle Stacking Asle Dav nrog pallet 1000 * 1200 hla rab rawg |
mm |
4150 |
|
Min. tig vojvoog |
mm |
2450 |
|
Kev ceev ceev, nrog / tsis muaj load |
km/h |
0-20 |
|
Lifting ceev, nrog / tsis muaj load |
mm/s |
450/470 |
|
Txo ceev, nrog / tsis muaj load |
mm/s |
490/430 |
|
Nce peev xwm |
% |
18 |
3 Tuj Gasoline Forklift txais cov roj hluav taws xob, uas tuaj yeem pib thiab nrawm nrawm hauv lub sijhawm luv. Nws kuj tseem muaj peev xwm pib txias txias thiab tuaj yeem hloov mus rau ntau qhov chaw huab cua. Qhov thib ob, lub braking system thiab ncua kev kawm ntawv ntawm cov khoom siv no muaj kev ua tau zoo heev, uas tuaj yeem ua kom muaj kev nyab xeeb thiab ruaj khov ntawm kev tsav tsheb. Tsis tas li ntawd, lub cev tsim yog tsim nyog thiab lub tsheb tavxij dav dav thiab xis nyob, muab tus neeg teb xov tooj nrog cov kab pom zoo thiab qhov chaw ua haujlwm zoo.
1.Tilting lub tog raj kheej uas yog hauv qab - teeb hom thiab lub rooj dav dav dav tsim rau tus neeg teb xov tooj txav ceg, yooj yim thiab dawb.
2. Cov roj teeb tsim nyog heev
3.Super elastic khoom log
4.Shock absorption systemSimple thiab txhim khu kev qha shock absorption tsim
Nuo Shington
pom lub cev
Standard Equipment >>>
1. Teev meter 2.Oil lub tswb nrov 3.Hydraulic lim 4. Lub teeb tiv thaiv 5. Tus thawj coj saib xyuas 6.Rov qab-txog buzzer 7.Hydraulic kauj 8.Standard diav rawg 9.Drawbar pin 10. Horn 11.Rov qab- tswb 12. Lub teeb ua haujlwm rov qab 13.2-stage mast 14. Awning 15.Standard rooj
Option >>>
1. Txawb 2. Siab tso pa tawm 3. Ncua lub rooj zaum 4. Fork extension 5. Lub log tsheb 6. Cuab cua 7. Cua sov 8. Dav dav dav ntawm rab rawg 9.Anti- hluav taws kub hnyiab 10. Cov neeg siv khoom xim 11.Lifting nuv 12. Cov ntaub pua plag sojntsuam 13. Sider shifter 14. Ib
FAQ
1. Vim li cas thiaj xaiv peb?
Raws li cov chaw tsim khoom, NUOXTON kev lag luam tau cog lus los muab cov khoom tsis yog cov khoom zoo thiab kev ua tau zoo thiab
tus nqi sib tw, tab sis kuj nyob rau hauv - lub sij hawm xa tuaj thiab ua tiav 7/24 tom qab - kev muag khoom.
2. Cov khoom lag luam ntawm koj lub Hoobkas yog dab tsi?
NUOXTON kev lag luam yog ib qho loj - nplai machinery manufacturing enterprise feem ntau tshwj xeeb hauv kev muab log loaders, forklift tsheb, excavator thiab lwm yam ntaub ntawv txuas. Peb kuj tuaj yeem kho cov khoom tsis yog - tus qauv raws li cov neeg siv khoom xav tau.
3. Cov nqe lus them nqi dab tsi koj tuaj yeem lees txais?
Feem ntau 30% tso nyiaj yuav tsum tau ua ntej, 70% tshuav nyiaj yuav tsum tau them ua ntej xa khoom. Thiab 100% irrevocable L / C thaum pom nrog cov nqe lus uas peb tau pom zoo kuj tuaj yeem lees txais.
4. Koj muaj daim ntawv pov thawj dab tsi?
Tag nrho cov khoom ua tau raws li ISO9001 Cov Txheej Txheem Zoo thiab tau txais daim ntawv pov thawj CE. Kev pom zoo EPA yuav muaj yog tias xav tau.
5. Yuav ua li cas txog koj lub sijhawm xa khoom?
Feem ntau nws yuav siv li 15 mus rau 30 hnub tom qab tau txais koj qhov tso nyiaj. Hais txog cov khoom txheem, peb ib txwm muaj hauv Tshuag thiab tuaj yeem xa tuaj sai. Tab sis cov khoom customized yuav siv sij hawm ntau dua, nyob ntawm seb koj qhov kev txiav txim yuav tsum tau ua.
6. Koj puas tuaj yeem muab kev pabcuam OEM?
NUOXTON kev lag luam tuaj yeem muab cov khoom lag luam customized raws li cov neeg siv khoom xav tau, ob qho tib si OEM thiab ODM tau txais.
Cim npe nrov: 3 Tuj Gasoline thiab LPG Roj Forklift Truck, Tuam Tshoj 3 Tuj Gasoline thiab LPG Roj Forklift Truck manufacturers, lwm tus neeg
